Birtley Steel Lintel CB90 is a versatile and robust solution for creating openings in masonry walls. With a length of 1200mm and a maximum opening of 900mm, this lintel is suitable for various applications in construction projects. Product Features: Dimensions: The lintel measures 1200mm in length, 280mm in depth, and 106mm in height. Maximum Opening: The maximum opening size is 900mm. Masonry Outer Leaf: The outer leaf of the masonry has a thickness of 100mm. Cavity: The cavity width ranges from 90mm to 110mm. Masonry Inner Leaf: The inner leaf of the masonry has a thickness of 100mm. Lintel Depth: The lintel depth is 280mm. Lintel Height: The lintel height is 106mm. Maximum UDL: The maximum uniformly distributed load is 15kN. Lintel Weight: The lintel weighs 7.08kg. Standard Duty: This lintel is designed for standard duty applications. Cavity Walls: It is suitable for use in cavity walls.

Read more less

Birtley Steel Lintel CB90 is a robust and reliable solution for supporting openings in masonry walls. With a length of 1500mm, this standard duty cavity lintel is suitable for openings with a maximum width of 1200mm and a cavity of 90-110mm. Its dimensions and load capacity make it an ideal choice for various construction projects. Product Features: Dimensions: The lintel measures 1500mm in length, 280mm in depth, and 106mm in height. Maximum Opening: It supports openings with a maximum width of 1200mm. Cavity: This lintel is designed for cavities ranging from 90mm to 110mm. Load Capacity: It can support a maximum uniformly distributed load (UDL) of 15kN. Weight: The lintel weighs 11.1kg, ensuring ease of handling during installation. Corrosion Protection: Birtley Steel Lintels feature hot-dip galvanization for superior corrosion protection.

Read more less

Birtley Supergalv Lintels are renowned for their superior corrosion protection. The lintel is hot-dip galvanized after fabrication, providing comprehensive coverage to all surfaces, edges, and welds. This process results in a minimum zinc coating thickness of 65um, which is significantly more than other lintels. The optional Ultragalv 2000 (U2k) corrosion protection system further enhances the lintels longevity by depositing a 150um thick zinc coating, offering up to 7 times more protection compared to other lintels. Product Features: Dimensions: 1800mm in length, 280mm in depth, and 132mm in height. Maximum Opening: Suitable for a maximum opening of 1500mm. Cavity: Suitable for a cavity of 90-110mm. Masonry Leaves: Suitable for 100mm thick masonry outer and inner leaves. Load-bearing Capacity: Maximum load-bearing capacity of 20kN. Weight: With a weight of 15.12kg, this lintel is easy to handle. Corrosion Protection: Hot-dip galvanized after fabrication, with optional Ultragalv 2000 (U2k) corrosion protection system.

Read more less

Birtley Steel Lintel CB90 is a versatile lintel that offers a robust solution for supporting openings in masonry walls. With a length of 2100mm, it is suitable for openings up to 1800mm. The lintels dimensions include a masonry outer leaf of 100mm, a cavity of 90mm-110mm, and a masonry inner leaf of 100mm. The lintel depth is 280mm and the lintel height is 138mm. It has a maximum UDL of 20kN and a weight of 17.64Kg. Product Features: Dimensions: The lintel measures 2100mm in length, 280mm in depth, and 138mm in height. Maximum Opening: Suitable for openings up to 1800mm. Masonry Leaves: Features a masonry outer leaf of 100mm and a masonry inner leaf of 100mm. Cavity: Suitable for cavities of 90mm-110mm. Lintel Weight: Weighs 17.64Kg. Lintel Type: Standard Duty Cavity Lintel. Material: Made of steel. Maximum UDL: Has a maximum UDL of 20kN.

Read more less

Birtley Steel Lintel CB90 is a robust and corrosion-resistant solution for creating openings in masonry walls. With a length of 2400mm, this standard duty cavity lintel is suitable for openings with a maximum size of 2100mm. It features a lintel height of 151mm and a depth of 280mm, making it an ideal choice for various construction projects. Product Features: Dimensions: Each lintel measures 2400mm in length, 280mm in depth, and 151mm in height. Maximum Opening: The lintel supports openings with a maximum size of 2100mm. Material: Made of steel for durability and strength. Lintel Weight: Weighing 24.96 kilograms, it offers a balance between ease of handling and robustness. Load Capacity: The lintel can support a maximum UDL (Uniformly Distributed Load) of 22 kN. Corrosion Protection: Hot-dip galvanized after manufacture for superior corrosion resistance.

Read more less

Birtley Steel Lintel CB90 is a robust and efficient cavity lintel designed for use in masonry constructions. This lintel, with a length of 2700mm, is a valuable addition to any building project, ensuring structural integrity and thermal efficiency. Product Features: Dimensions: The lintel has a length of 2700mm, a width of 280mm, and a height of 181mm. Maximum Opening: Suitable for openings with a maximum of 2400mm. Masonry Outer Layer: Designed for a 100mm masonry outer layer. Cavity: Suitable for cavities between 90mm and 110mm. Masonry Inner Layer: Designed for a 100mm masonry inner layer. Maximum Load Capacity: Capable of supporting a maximum load of 26kN. Weight: Weighing 32.4kg, this lintel offers a balance between durability and ease of handling.

Read more less

Birtley Steel Lintel CB90 is a versatile and robust solution for supporting openings in masonry walls. With a length of 3000mm, this lintel is suitable for various applications, accommodating a maximum opening of 2700mm and cavities between 90mm and 110mm. Product Features: Dimensions: The lintel measures 3000mm in length, 280mm in depth, and 181mm in height. Maximum Opening: It supports openings up to 2700mm in width. Cavity: This lintel is designed for cavities between 90mm and 110mm. Load Capacity: It can support a maximum uniformly distributed load (UDL) of 26kN. Weight: The lintel weighs 36kg, ensuring stability and durability. Corrosion Protection: Birtley Steel Lintels are hot-dip galvanized after manufacturing, providing superior corrosion protection.

Read more less

Birtley CB90 Steel Lintel is a robust and efficient solution for creating openings in masonry structures. This standard duty cavity lintel, with a length of 900mm, is designed for ease of installation and to maintain thermal values of wall construction. It is manufactured from high-grade, flame retardant EPS insulation and features a single thickness of steel for simplified locating within brickwork joints. Product Features: Dimensions: The lintel measures 900mm in length, 280mm in depth, and 97mm in height. Maximum Opening: Suitable for openings with a maximum opening of 600mm. Masonry Outer Leaf: Designed for a masonry outer leaf of 100mm. Cavity: Suitable for cavities ranging from 90mm to 110mm. Masonry Inner Leaf: Designed for a masonry inner leaf of 100mm. Lintel Depth: The lintel has a depth of 280mm. Lintel Height: The lintel has a height of 97mm. Maximum UDL: The maximum unit dead load is 15kN. Lintel Weight: The lintel weighs 5.31kg.

Read more less
